A4-70CAP




Due to the presence of Mo in the basic composition, it has high strength even at high temperatures.
A4-70 hexagon socket head screws
Material: SUS316L
Strength level: A4-70
Tensile strength: 700Mpa
Stress corrosion resistance: The resistance to stress corrosion cracking is better than SUS304.
Magnetic permeability: 1.01~1.03μ
Manufacturing specifications: JIS B 1176
Thread specifications: JIS B 0205
Thread series: 6g
Surface treatment: passivation treatment
Commonly used in FPD manufacturing equipment/semiconductor manufacturing equipment/marine equipment/general industrial machinery, showing better resistance to chemicals and marine environments than SUS304 corrosion resistance. It also surpasses SUS304/SUSXM7 in terms of non-magnetic properties and is often used in medical equipment.
